Nakamichi NDS-10B Bluetooth Module For Digital Signal Processor (DSP)

$49.95

Compare

Description

Nakamichi NDS-10B Bluetooth Module For Digital Signal Processor (DSP)

Our Nakamichi NDS-10B extends all compatible Nakamichi DSP products with Bluetooth audio streaming function as well as application control through your mobile device.

Provide direct digital signals to your Nakamichi DSP for lossless audio processing, and retain your original sound.

Specifications:

  • Working Frequency Band: 2.402 – 2.480 GHz, ISM Band
  • Bluetooth: Bluetooth V4.0 Dual Mode
  • Master Chip: CSR8670
  • Power Level: Class ǁ
  • Effective Distance: 10m for Empty Area(Typical)
  • Transmit Power:+4dBm(typical)
  • Receiver Sensitivity: -88dB at 0.1%BER(Typical)
  • Frequency Deviation: ±10K Hz
  • Supply Voltage: 3.3V
  • Uint Dimensions: 60×22×90mm
  • Net Mass: Approx. 0.05kg



Download: Nakamichi NDS-10B User Manual

Additional information

Weight 0.5 kg
